You are here: Bearing housings and units Bearing units Cast iron housing units UKFB 206 K/H SKF
UKFB 206 K/H
UKFB 206 K/H
UKFB 206 K/H
UKFB 206 K/H

Cast iron bearing unit without adapter sleeve

UKFB 206 K/H SKF

dimensions 25 x 0 x 0
Weight 0.89 kg
A1 [mm] 10
A [mm] 30
clearence C3 - greater than normal
dynamic load rating [N] 19500
d [mm] 25
F2 [mm] 137
H1 [mm] 29
H [mm] 50
J [mm] 40
L2 [mm] 20
limiting speed [rpm] 5000
Log in to ask for price and availability
Attributes Works with

UKFB 206 K/H SKF

Cast iron bearing unit without adapter sleeve

Attributes
manufacturer SKF
dimensions 25 x 0 x 0
Weight 0.89 kg
A [mm] 30
d [mm] 25
H [mm] 50
H1 [mm] 29
L [mm] 83
L2 [mm] 20
clearence C3 - greater than normal
N [mm] 9.5
type Cast iron bearing unit without adapter sleeve
A1 [mm] 10
J [mm] 40
F2 [mm] 137
dynamic load rating [N] 19500
static load rating [N] 11200
taper taper 1:12
limiting speed [rpm] 5000

Technical materials

Works with
Product
H 2306 SKF

H 2306 SKF

 Adapter sleeve
