You are here: Linear motion Linear bearings Linear ball bearings LQCD 12 D-2LS EWELLIX

Linear ball bearing unit

LQCD 12 D-2LS EWELLIX

Name: LQCD 12 D-2LS EWELLIX
Rating: 4.7 (15 reviews)

dimensions	12 x 0 x 85
Weight	0.512 kg
dynamic load rating [N]	2850
d [mm]	12
F - height to the axis [mm]	16
H [mm]	32
J [mm]	73
K [mm]	73
L [mm]	85
norm	EU
sealing	single-lip seal
static load rating [N]	3250
type	Linear ball bearing unit

Attributes Works with

LQCD 12 D-2LS EWELLIX

Linear ball bearing unit

Attributes

manufacturer	EWELLIX
dimensions	12 x 0 x 85
Weight	0.512 kg
d [mm]	12
F - height to the axis [mm]	16
H [mm]	32
L [mm]	85
norm	EU
type	Linear ball bearing unit
sealing	single-lip seal
W [mm]	85
used with	2201556
used with	2201567
used with	2201581
used with	2201597
used with	2201590
J [mm]	73
K [mm]	73
dynamic load rating [N]	2850
static load rating [N]	3250
