Name: 619-28872-1 SKF
Rating: 4.9 (5 reviews)

619-28872-1 SKF

MET.DEV. SSV 16-K

Weight

1.86 kg

additional description

Progressive metering devices in block design

application

Construction and mining Agriculture machinery Industrial equipment Renewable energies

connection outlet

M10x1

cycle Indicator

Cycle indicator pin

metering quantity

0,2 cm³ per stroke

operating temperature

–40÷200°C

type

Metering device

used with

grease up to NLGI 2, oil with a viscosity of min 40 mm2/s

working pressure [bar]

max. 400 bar

Details Attributes

619-28872-1 SKF

Metering device

Sizes up to 22 outlets.
High operating pressure.
Available in different materials.
Exact lubricant metering.
Unique internal crossporting technology.
Optionally equipped with visual monitoring pin or with electrically monitored piston detector.
SSV type metering device is a compact, single block progressive metering device.
For direct mount of fittings with no need of any sealing in between.
Available with pin indicator for visual system monitoring or with piston detector for electrical system monitoring.

Attributes

manufacturer	SKF
dimensions	0 x 0 x 0
Weight	1.86 kg
working pressure [bar]	max. 400 bar
operating temperature	–40÷200°C
type	Metering device
used with	grease up to NLGI 2, oil with a viscosity of min 40 mm2/s
application	Construction and mining Agriculture machinery Industrial equipment Renewable energies
additional description	Progressive metering devices in block design
metering quantity	0,2 cm³ per stroke
connection outlet	M10x1
cycle Indicator	Cycle indicator pin
