Name: TLGB 20 SKF
Rating: 4.8 (2 reviews)

TLGB 20 SKF

Weight

5.843 kg

country of origin

Netherlands / China

grease output [ml/min]

100

includes

Carrying strap for battery driven grease gun: TLGB 20-1

includes

20V Li-Ion battery for battery driven grease gun: TLGB 20-2

includes

High pressure hose 900 mm (36 in) with coupler for battery driven grease gun: TLGB 20-3

includes

Grease tube assembly for battery driven grease gun: TLGB 20-4

includes

Charger 220-240V for battery driven grease gun: TLGB 20-5

pipe

900mm

type

grease gun

used with

TLGB 1230

used with

TLGB 1248HP

Details Attributes Substitutes (2)

TLGB 20 SKF

Grease gun

Developed for maximum efficiency, the SKF Battery Driven Grease Gun TLGB 20 includes an integrated grease meter to help prevent over- and under-lubrication. This unique tool features a durable, ergonomic design with a three-point stand for operator comfort and convenience and a lithium-ion battery for longer life. The tool’s display indicates battery charge level, amount of grease dispensed, pump/motor speed and blocked lubrication points. This versatile grease gun provides two flow rates – low and high – and can dispense up to 15 grease cartridges per battery charge. The TLGB 20 can deliver pressures up to 700 bar (10000 psi) and features a built-in light to illuminate the work area.

Integrated grease meter tracks dispensed grease.
Battery charge display indicates lithium battery charge level.
LED light illuminates work area to help locate grease fittings in dimly lit environments.
Lithium-ion battery dispenses up to 15 grease cartridges per charge and maintains stable energy output.
Filler nipple facilitates clean and simple filling from drums using filler pumps. Lightweight, ergonomic design with optimized balance for operator comfort.

manufacturer	SKF
dimensions	0 x 0 x 0
Weight	5.843 kg
type	grease gun
used with	TLGB 1230
used with	TLGB 1248HP
used with	TLGB 1871
used with	TLGB 1872
used with	TLGB 1875A
used with	TLGB 20-7
includes	Carrying strap for battery driven grease gun: TLGB 20-1
includes	20V Li-Ion battery for battery driven grease gun: TLGB 20-2
includes	High pressure hose 900 mm (36 in) with coupler for battery driven grease gun: TLGB 20-3
includes	Grease tube assembly for battery driven grease gun: TLGB 20-4
includes	Charger 220-240V for battery driven grease gun: TLGB 20-5
pipe	900mm
grease output [ml/min]	100
country of origin	Netherlands / China
