You are here: Bearings Spherical roller bearings Simple spherical roller bearings 21305-E1-XL-TVPB FAG

Spherical roller bearing

21305-E1-XL-TVPB FAG

Name: 21305-E1-XL-TVPB FAG
Rating: 4.9 (11 reviews)

dimensions	25 x 62 x 17
Weight	0.257 kg
cage	polyamide
clearence	CN - normal clearance
country of origin	Germany
dynamic load rating [N]	52000
limiting speed [rpm]	13900
operating temperature	-30÷120°C
reference speed [rpm]	8400
reinforced execution	yes
static load rating [N]	43500
type	Spherical roller bearing

Plewiska (17)

on stock

Katowice (4)

on stock

Attributes Substitutes (4)

21305-E1-XL-TVPB FAG

Spherical roller bearing

Attributes

manufacturer	FAG
dimensions	25 x 62 x 17
Weight	0.257 kg
clearence	CN - normal clearance
operating temperature	-30÷120°C
type	Spherical roller bearing
reinforced execution	yes
dynamic load rating [N]	52000
static load rating [N]	43500
cage	polyamide
country of origin	Germany
limiting speed [rpm]	13900
reference speed [rpm]	8400
