You are here: Bearings Ball bearings Angular contact ball bearings HCS71913-E-T-P4S-UL CSC
HCS71913-E-T-P4S-UL

Single row angular-contact ball bearing, high precision bearing

HCS71913-E-T-P4S-UL CSC

dimensions 65 x 90 x 13
Weight 0.18 kg
bearing arrangement for universal matching
cage textolite, outer ring centred
contact angle [°] 25
country of origin China
Dynamic load rating [N] 13420
limiting/attainable speed, grease [rpm] 22000
precision better than P4
preload light preload
product feature high precision bearing
rolling element material small ceramic balls
sealing two-sided rubber, non-contact
Plewiska (45)

on stock
Log in to see the price
Attributes Substitutes (8)

HCS71913-E-T-P4S-UL CSC

Single row angular-contact ball bearing, high precision bearing

Attributes
manufacturer CSC
dimensions 65 x 90 x 13
Weight 0.18 kg
type single row angular-contact ball bearing
sealing two-sided rubber, non-contact
product feature high precision bearing
Dynamic load rating [N] 13420
static load rating [N] 13690
contact angle [°] 25
cage textolite, outer ring centred
preload light preload
bearing arrangement for universal matching
precision better than P4
country of origin China
limiting/attainable speed, grease [rpm] 22000
rolling element material small ceramic balls

Technical materials

Product's substitutes
Product
dimensions
availability
Net price
65BER19HTXV1VQUELP3 NSK

65BER19HTXV1VQUELP3 NSK

 Single row angular-contact ball bearing, high precision ball bearings set, (four pcs)

65 x 90 x 13
HCB71913-E-2RSD-T-P4S-UL FAG

HCB71913-E-2RSD-T-P4S-UL FAG

 Single row angular-contact ball bearing, high precision bearing

65 x 90 x 13

in stock

Plewiska: 8 pcs

Log in to see prices
B71913-E-2RSD-T-P4S-UL CSC

B71913-E-2RSD-T-P4S-UL CSC

 Single row angular-contact ball bearing, high precision bearing

65 x 90 x 13

in stock

Plewiska: 4 pcs

Log in to see prices
B71913-E-2RSD-T-P4S-UL FAG

B71913-E-2RSD-T-P4S-UL FAG

 Single row angular-contact ball bearing, high precision bearing

65 x 90 x 13

in stock

Plewiska: 2 pcs

Log in to see prices
HCB71913-E-2RSD-T-P4S-UL CSC

HCB71913-E-2RSD-T-P4S-UL CSC

 Single row angular-contact ball bearing, high precision bearing

65 x 90 x 13

in stock

Plewiska: 4 pcs

Log in to see prices
HCS71913-E-T-P4S-UL FAG

HCS71913-E-T-P4S-UL FAG

 Single row angular-contact ball bearing, high precision bearing

65 x 90 x 13

in stock

Plewiska: 19 pcs

Log in to see prices
HY KH 61913 2RZ E TA P4+ UL T274 GMN

HY KH 61913 2RZ E TA P4+ UL T274 GMN

 Single row angular-contact ball bearing, high precision bearing

65 x 90 x 13

in stock

Plewiska: 12 pcs

Log in to see prices
S71913 ACEGA/HCP4A SKF

S71913 ACEGA/HCP4A SKF

 Single row angular-contact ball bearing, high precision bearing

65 x 90 x 13

in stock

ok. 2 tygodnie: 6 pcs

Log in to see prices
