SYJ 60 TF SKF
Cast iron bearing unit
manufacturer | SKF |
dimensions | 60 x 0 x 0 |
Weight | 4.841 kg |
A [mm] | 65 |
d [mm] | 60 |
F [mm] | 69.8 |
L [mm] | 241 |
clearence | C3 - greater than normal |
N [mm] | 20 |
type | cast iron bearing unit |
A1 [mm] | 47 |
J [mm] | 188.5 |
F2 [mm] | 138 |
Dynamic load rating [N] | 52700 |
static load rating [N] | 36000 |
country of origin | Italy |
limiting speed [rpm] | 3400 |
