You are here: Power transmission Couplings Taper-lock sleeves TAPER LOCK 1108-24 SIT

Taper-lock bush

TAPER LOCK 1108-24 SIT

Name: TAPER LOCK 1108-24 SIT
Rating: 4.5 (13 reviews)

BC1108F24 SIT

dimensions	24 x 38 x 22.3
Weight	0.1 kg
b [mm]	8
country of origin	China
feature	taper lock bush for mounting pulleys
feature	4 holes
material	grey cast iron
mounting holes number	2
screw tightening torque [Nm]	5.6
t2 [mm]	3.3
transmissible axial load [kN]	5220
transmissible torque moment [Nm]	147
type	taper-lock bush

Plewiska (24)

on stock

Attributes Substitutes (2)

TAPER LOCK 1108-24 SIT

Taper-lock bush

manufacturer	SIT
dimensions	24 x 38 x 22.3
Weight	0.1 kg
b [mm]	8
feature	taper lock bush for mounting pulleys
feature	4 holes
mounting holes number	2
material	grey cast iron
screw tightening torque [Nm]	5.6
transmissible torque moment [Nm]	147
transmissible axial load [kN]	5220
t2 [mm]	3.3
type	taper-lock bush
country of origin	China
