You are here: Power transmission Couplings Clamping sleeves CAL1F130/180 SIT

Clamping element, SIT-LOCK, not self-centering

CAL1F130/180 SIT

dimensions 130 x 180 x 38
Weight 3.685 kg
clamping screw M12
country of origin China
feature no axial displacement when tightening the screws
H2 [mm] 50
H [mm] 34
material steel
mounting holes number 20
product feature sit-lock
product feature not self-centering
screw tightening torque [Nm] 127
transmissible axial load [kN] 275
Plewiska (58)

on stock

CAL1F130/180 SIT

Clamping element, SIT-LOCK, not self-centering

Attributes
manufacturer SIT
dimensions 130 x 180 x 38
Weight 3.685 kg
feature no axial displacement when tightening the screws
H [mm] 34
H2 [mm] 50
mounting holes number 20
material steel
screw tightening torque [Nm] 127
transmissible torque moment [Nm] 17850
transmissible axial load [kN] 275
type clamping element
product feature sit-lock
product feature not self-centering
country of origin China
clamping screw M12

Technical materials

Product's substitutes
Product
dimensions
availability
Net price

PHF FX10-130X180 SKF

Clamping element, not self-centering

130 x 180 x 38
