You are here: Power transmission Couplings Clamping sleeves CAL5A-F45/75 SIT
CAL5AF45/75

Clamping element, SIT-LOCK, self-centering

CAL5A-F45/75 SIT

dimensions 45 x 75 x 52
Weight 0.989 kg
clamping screw M8
country of origin China
feature axial displacement when tightening screws
H1 [mm] 35
H2 [mm] 30
Ht [mm] 60
material steel
mounting holes number 6
product feature self-centering
product feature sit-lock
screw tightening torque [Nm] 41
Plewiska (47)

on stock
Log in to see the price
Attributes

CAL5A-F45/75 SIT

Clamping element, SIT-LOCK, self-centering

manufacturer SIT
dimensions 45 x 75 x 52
Weight 0.989 kg
feature axial displacement when tightening screws
H1 [mm] 35
H2 [mm] 30
Ht [mm] 60
mounting holes number 6
material steel
screw tightening torque [Nm] 41
transmissible torque moment [Nm] 2275
transmissible axial load [kN] 101
type clamping element
product feature self-centering
product feature sit-lock
country of origin China
clamping screw M8
