Clamping element, SIT-LOCK, self-centering

CAL5A-F80/120 SIT

Name: CAL5A-F80/120 SIT
Rating: 4.7 (12 reviews)

dimensions	80 x 120 x 57
Weight	2.51 kg
clamping screw	M10
country of origin	Italy
feature	axial displacement when tightening screws
H1 [mm]	46
H2 [mm]	40
Ht [mm]	67
material	steel
mounting holes number	7
product feature	self-centering
product feature	sit-lock
screw tightening torque [Nm]	83

Plewiska (49)

on stock

Attributes Substitutes (1)

CAL5A-F80/120 SIT

Clamping element, SIT-LOCK, self-centering

Attributes

manufacturer	SIT
dimensions	80 x 120 x 57
Weight	2.51 kg
feature	axial displacement when tightening screws
H1 [mm]	46
H2 [mm]	40
Ht [mm]	67
mounting holes number	7
material	steel
screw tightening torque [Nm]	83
transmissible torque moment [Nm]	7491
transmissible axial load [kN]	187
type	clamping element
product feature	self-centering
product feature	sit-lock
country of origin	Italy
clamping screw	M10

Technical materials

Product's substitutes

PHF FX40-80X120 SKF

Clamping element, self-centering

80 x 120 x 45
