You are here: Pneumatics and hydraulics Shock absorbers YSRW-10-17 FESTO

Hydraulic damper

YSRW-10-17 FESTO

Name: YSRW-10-17 FESTO
Rating: 4.9 (5 reviews)

191195 FESTO

Details Attributes

YSRW-10-17 FESTO

Hydraulic damper

Feature	Value
Size	10
Stroke	17 mm
Cushioning	self-adjusting Soft characteristic
Assembly position	Any
Position detection	No
Max. impact speed	3 m/s
Reset time short	0.2 s
Reset time long	1 s
Mode of operation	single-acting pushing action
Corrosion resistance classification CRC	2 - Moderate corrosion stress
Ambient temperature	-10 ... 80 °C
Cushioning length	17 mm
Max. stop force	700 N
Max. energy consumption per stroke	8 J
Max. energy consumption per hour	30,000 J
Max. residual energy	0.03 J
Reset force	3.5 N
Product weight	54 g
Mounting type	with lock nut
Materials note	Free of copper and PTFE Conforms to RoHS
Material seals	NBR
Material housing	Steel Galvanised
Material piston rod	High alloy steel
