You are here: Pneumatics and hydraulics Vacuum gauges and generators VAD-1/4 FESTO

Vacuum generators

VAD-1/4 FESTO

Name: VAD-1/4 FESTO
Rating: 4.9 (1 reviews)

9394 FESTO 9394 FESTO 9394 FESTO

Plewiska (10)

on stock

Details Attributes

VAD-1/4 FESTO

Vacuum generators

Feature	Value
Nominal size, Laval nozzle	1 mm
Assembly position	Any
Ejector characteristic	High vacuum
Design structure	T-shaped
Operating pressure	1.5 ... 10 bar
Max. vacuum	80 %
Operating medium	Compressed air in accordance with ISO8573-1:2010 [7:4:4]
Note on operating and pilot medium	Lubricated operation possible (subsequently required for further operation)
Medium temperature	-20 ... 80 °C
Ambient temperature	-20 ... 80 °C
Mounting type	with through hole
Pneumatic connection, port 1	G1/4
Pneumatic connection, port 3	G1/4
Vacuum connection	G1/4
Materials note	Free of copper and PTFE
Material housing	Aluminium die cast
