MS2-LR-QS6-D6-AR-BAR-B FESTO

8086638 FESTO 8086638 FESTO 8086638 FESTO

Weight

0.04 kg

country of origin

Hungary

sealing material

NBR

type

reducer

working medium

Gazy obojętne, sprężone powietrze wg ISO8573-1:2010 [7:4:4]

working pressure [bar]

1÷8

zakres regulacji ciśnienia [bar]

0,5÷7

Details Attributes

MS2-LR-QS6-D6-AR-BAR-B FESTO

Reducer

Data sheet:

Name: MS2-LR-QS6-D6-AR-BAR-B FESTO
Rating: 4.5 (4 reviews)

Feature	Value
Size	2
Series	MS
Actuator lock	Rotary knob with lock
Assembly position	Any
Design structure	directly-controlled diaphragm regulator
Controller function	Output pressure constant with secondary exhaust with return flow
Unit(s) that can be displayed	bar psi
Pressure gauge	with pressure gauge
Operating pressure MPa	0.1 ... 0.8 MPa
Operating pressure	1 ... 8 bar
Pressure regulation range	0.5 ... 7 bar
Max. pressure hysteresis	0.25 bar
Standard nominal flow rate	350 l/min
Operating medium	Compressed air in accordance with ISO8573-1:2010 [7:4:4] Inert gases
Corrosion resistance classification CRC	1 - Low corrosion stress
Storage temperature	-5 ... 50 °C
Medium temperature	-5 ... 50 °C
Ambient temperature	-5 ... 50 °C
Product weight	36.6 g
Mounting type	Front panel installation Line installation with accessories Optional
Pneumatic connection, port 1	QS-6
Pneumatic connection, port 2	QS-6
Materials note	Conforms to RoHS
Material underneath cover	PA
Material seals	NBR
Material rotary knob	POM
Material spring	High alloy steel
Material housing	PA
Material membrane	NBR
Material valve stem	Wrought Aluminium alloy NBR

Attributes

manufacturer	FESTO
dimensions	0 x 0 x 0
Weight	0.04 kg
working pressure [bar]	1÷8
sealing material	NBR
type	reducer
country of origin	Hungary
zakres regulacji ciśnienia [bar]	0,5÷7
working medium	Gazy obojętne, sprężone powietrze wg ISO8573-1:2010 [7:4:4]
