Name: SUCP206CO SNR
Rating: 4.5 (7 reviews)

SUCP206CO SNR

dimensions

30 x 0 x 0

Weight

1.59 kg

A [mm]

cage

stainless steel

clearence

C3 - greater than normal

country of origin

China

Dynamic load rating [N]

15300

d [mm]

F2 [mm]

F [mm]

42.9

grease

grease for the food a compliant with NSF-H1 recommendations

groove in housing for fixing protective caps

yes

J [mm]

121

Attributes Substitutes (8)

SUCP206CO SNR

Stainless steel ball bearing unit with open end

manufacturer	SNR
dimensions	30 x 0 x 0
Weight	1.59 kg
A [mm]	48
d [mm]	30
F [mm]	42.9
groove in housing for fixing protective caps	yes
L [mm]	165
clearence	C3 - greater than normal
grease	grease for the food a compliant with NSF-H1 recommendations
type	stainless steel ball bearing unit with open end
sealing	double-sided lip seal covered with a steel sheet washers with outer flinger shield with corrosion protection.
J [mm]	121
F2 [mm]	83
Dynamic load rating [N]	15300
static load rating [N]	11500
cage	stainless steel
country of origin	China
