You are here: Bearing housings and units Bearing units Cast iron housing units RSHEY20-XL-N INA

Cast iron bearing unit

RSHEY20-XL-N INA

Name: RSHEY20-XL-N INA
Rating: 4.9 (1 reviews)

dimensions	20 x 0 x 0
Weight	0.47 kg
A1 [mm]	19
A [mm]	32
cage	polyamide
clearence	C3 - greater than normal
country of origin	Vietnam
d [mm]	20
F2 [mm]	64
F [mm]	33.3
groove in housing for fixing protective caps	yes
groove on outer ring	yes
J [mm]	50.8

Plewiska (8)

on stock

Attributes Substitutes (2)

RSHEY20-XL-N INA

Cast iron bearing unit

manufacturer	INA
dimensions	20 x 0 x 0
Weight	0.47 kg
A [mm]	32
d [mm]	20
F [mm]	33.3
groove in housing for fixing protective caps	yes
thread	M8
L [mm]	65
clearence	C3 - greater than normal
groove on outer ring	yes
type	cast iron bearing unit
sealing	double-sided lip seal covered with a plate
A1 [mm]	19
J [mm]	50.8
F2 [mm]	64
cage	polyamide
country of origin	Vietnam
