Name: DGE 40 SW DURBAL
Rating: 4.7 (10 reviews)

DGE 40 SW DURBAL

dimensions

40 x 68 x 19

Weight

0.337 kg

C - outer ring width [mm]

Dynamic load rating [N]

134000

dz - inner diameter of the outer ring [mm]

46.8

D [mm]

d [mm]

friction pair

steel/steel

inner ring width [mm]

max. tilt angle [°]

1.9

norm

DIN ISO 12240-2

product line

Basic line

sealing

none

Attributes Substitutes (4)

DGE 40 SW DURBAL

Angular contact spherical plain bearing

Attributes

manufacturer	DURBAL
dimensions	40 x 68 x 19
Weight	0.337 kg
inner ring width [mm]	18
C - outer ring width [mm]	18
d [mm]	40
D [mm]	68
dz - inner diameter of the outer ring [mm]	46.8
norm	DIN ISO 12240-2
friction pair	steel/steel
T [mm]	19
type	angular contact spherical plain bearing
sealing	none
Dynamic load rating [N]	134000
static load rating [N]	270000
product line	Basic line
max. tilt angle [°]	1.9
