You are here: Bearings Ball bearings Angular contact ball bearings HCM7010-E-2RSD-T-P4S-UL-XL FAG
HCM7010-E-2RSD-T-P4S-UL-XL

Single row angular-contact ball bearing, high precision bearing

HCM7010-E-2RSD-T-P4S-UL-XL FAG

dimensions 50 x 80 x 16
Weight 0.256 kg
bearing arrangement for universal matching
cage textolite, outer ring centred
contact angle [°] 25
country of origin
Dynamic load rating [N] 12500
grease tak
limiting/attainable speed, grease [rpm] 30000
precision better than P4
preload light preload
product feature high precision bearing
rolling element material medium ceramic balls
Log in to ask for price and availability
Attributes Substitutes (19)

HCM7010-E-2RSD-T-P4S-UL-XL FAG

Single row angular-contact ball bearing, high precision bearing

manufacturer FAG
dimensions 50 x 80 x 16
Weight 0.256 kg
grease tak
type single row angular-contact ball bearing
sealing two-sided rubber, non-contact
product feature high precision bearing
Dynamic load rating [N] 12500
static load rating [N] 6700
contact angle [°] 25
cage textolite, outer ring centred
preload light preload
bearing arrangement for universal matching
precision better than P4
country of origin
limiting/attainable speed, grease [rpm] 30000
rolling element material medium ceramic balls

Technical materials

Product's substitutes
Product
dimensions
availability
Net price
50BNR10HTSUELP3 NSK

50BNR10HTSUELP3 NSK

 Single row angular-contact ball bearing, high precision bearing

50 x 80 x 16

in stock

Plewiska: 17 pcs

Log in to see prices
50BNR10STSUELP3 NSK

50BNR10STSUELP3 NSK

 Single row angular-contact ball bearing, high precision bearing

50 x 80 x 16

in stock

Plewiska: 6 pcs

Log in to see prices
50BNR10STV1VSUELP3 NSK

50BNR10STV1VSUELP3 NSK

 Single row angular-contact ball bearing, high precision bearing

50 x 80 x 16

in stock

Plewiska: 12 pcs

Log in to see prices
7010 FE/HCDBAGMM3VQ126 SKF

7010 FE/HCDBAGMM3VQ126 SKF

 Single row angular-contact ball bearing, high precision ball bearings set, (two pcs)

50 x 80 x 16
7010 FE/HCDGG3VQ672F2 SKF

7010 FE/HCDGG3VQ672F2 SKF

 Single row angular-contact ball bearing, high precision ball bearings set, (two pcs)

50 x 80 x 16

in stock

Plewiska: 1 pair

Log in to see prices
7010 FE/HCP4AH1DGA SKF

7010 FE/HCP4AH1DGA SKF

 Single row angular-contact ball bearing, high precision ball bearings set, (two pcs)

50 x 80 x 16
7010 FE/HCP4AH1DT SKF

7010 FE/HCP4AH1DT SKF

 Single row angular-contact ball bearing, high precision ball bearings set, (two pcs)

50 x 80 x 16

in stock

Plewiska: 1 pair

Log in to see prices
7010 FE/HCP4AH1DTVK360 SKF

7010 FE/HCP4AH1DTVK360 SKF

 Single row angular-contact ball bearing, high precision ball bearings set, (two pcs)

50 x 80 x 16

in stock

Plewiska: 1 pair

Log in to see prices
7010 FE/HCP4AL1DTVK360 SKF

7010 FE/HCP4AL1DTVK360 SKF

 Single row angular-contact ball bearing, high precision ball bearings set, (two pcs)

50 x 80 x 16
7010 FE/HCP4ALDGA SKF

7010 FE/HCP4ALDGA SKF

 Single row angular-contact ball bearing, high precision ball bearings set, (two pcs)

50 x 80 x 16
7010 FE/HCPA9ADBG2V036F3 SKF

7010 FE/HCPA9ADBG2V036F3 SKF

 Single row angular-contact ball bearing, high precision ball bearings set, (two pcs)

50 x 80 x 16
7010 FE/HCPA9ATBTLV036F3 SKF

7010 FE/HCPA9ATBTLV036F3 SKF

 Single row angular-contact ball bearing, high precision ball bearings set, (three pcs)

50 x 80 x 16
7010 FEGA/HCP4A SKF

7010 FEGA/HCP4A SKF

 Single row angular-contact ball bearing, high precision bearing

50 x 80 x 16

in stock

Plewiska: 2 pcs

Log in to see prices
7010 FEGA/HCP4AH1 SKF

7010 FEGA/HCP4AH1 SKF

 Single row angular-contact ball bearing, high precision bearing

50 x 80 x 16

in stock

Plewiska: 2 pcs

Log in to see prices
7010 FEGA/HCP4AL SKF

7010 FEGA/HCP4AL SKF

 Single row angular-contact ball bearing, high precision bearing

50 x 80 x 16
7010 FEGA/HCP4AL2 SKF

7010 FEGA/HCP4AL2 SKF

 Single row angular-contact ball bearing, high precision bearing

50 x 80 x 16
HY KH 6010 2RZ C TA P4+ DUL T274 GMN

HY KH 6010 2RZ C TA P4+ DUL T274 GMN

 Single row angular-contact ball bearing, high precision ball bearings set, (two pcs)

50 x 80 x 16

in stock

Plewiska: 6 pair

Log in to see prices
HY SM 6010 17° TA P4+ UL GMN

HY SM 6010 17° TA P4+ UL GMN

 Single row angular-contact ball bearing, high precision bearing

50 x 80 x 16
HY SM 6010 18° TXM P4+ UL GMN

HY SM 6010 18° TXM P4+ UL GMN

 Single row angular-contact ball bearing, high precision bearing

50 x 80 x 16

in stock

Plewiska: 4 pcs

Log in to see prices
