You are here: Power transmission Couplings Zero backlash helical couplings GN 2246-25-B6-8-AL ELESA

Helical coupling backlash free

GN 2246-25-B6-8-AL ELESA

Name: GN 2246-25-B6-8-AL ELESA
Rating: 4.8 (3 reviews)

dimensions	6 x 25 x 31
Weight	0.035 kg
additional description	jaw coupling with finished bore, without keyway
d1 [mm]	6
d2 [mm]	8
hardness	80ShA, internal combustion engines (very wide movement dynamic), damping of very large vibrations
material	aluminium
max. angular displacement [°]	2
max. axial displacement [mm]	0.4
max. radial displacement [mm]	0.15
max. velocity [rpm]	25000
type	helical coupling backlash free

Attributes

GN 2246-25-B6-8-AL ELESA

Helical coupling backlash free

Attributes

manufacturer	ELESA
dimensions	6 x 25 x 31
Weight	0.035 kg
d1 [mm]	6
material	aluminium
max. angular displacement [°]	2
max. axial displacement [mm]	0.4
max. radial displacement [mm]	0.15
max. velocity [rpm]	25000
hardness	80ShA, internal combustion engines (very wide movement dynamic), damping of very large vibrations
type	helical coupling backlash free
additional description	jaw coupling with finished bore, without keyway
d2 [mm]	8
