You are here: Linear motion Linear guides and carriages Profile guides and carriages KWVE35-B-V2-G3 INA

Linear recirculating ball bearing

KWVE35-B-V2-G3 INA

dimensions	0 x 100 x 112
Weight	1.874 kg
country of origin	Romania
Dynamic load rating [N]	38000
precision	high accuracy
preload	high preload
rail size	35
static load rating [N]	72000
static moment rating about X axis [Nm]	1465
static moment rating about Z axis [Nm]	1020
type	linear recirculating ball bearing

Plewiska (17)

on stock

Log in to see the price

INA

Attributes Substitutes (4) Works with

KWVE35-B-V2-G3 INA

Linear recirculating ball bearing

Log in to see the price

Attributes

manufacturer	INA
dimensions	0 x 100 x 112
Weight	1.874 kg
rail size	35
type	linear recirculating ball bearing
Dynamic load rating [N]	38000
static load rating [N]	72000
preload	high preload
precision	high accuracy
country of origin	Romania
static moment rating about X axis [Nm]	1465
static moment rating about Z axis [Nm]	1020

Technical materials

Product's substitutes

KWVE35-B-V2-G1 INA

KWVE35-B-V2-G1 INA

Linear recirculating ball bearing

0 x 100 x 112

in stock

Plewiska: 12 pcs

Log in to see prices

KWVE35-B-V0-G3 INA

KWVE35-B-V0-G3 INA

Linear recirculating ball bearing

0 x 100 x 112

in stock

Plewiska: 3 pcs

Log in to see prices

KWVE35-B-V1-G3 INA

KWVE35-B-V1-G3 INA

Linear recirculating ball bearing

0 x 100 x 112

in stock

Plewiska: 71 pcs

Log in to see prices

KWVE35-B-V0-G4 INA

KWVE35-B-V0-G4 INA

Linear recirculating ball bearing

0 x 100 x 112

in stock

Plewiska: 12 pcs

Log in to see prices

Works with

TKVD35-G3 /6000 INA

TKVD35-G3 /6000 INA

Rail (operating temp.: -10÷100°C)

TKVD35-U-G3 /6000 INA

TKVD35-U-G3 /6000 INA

Rail with threaded holes (operating temp.: -10÷100°C)
