Name: 29317-E1-XL FAG
Rating: 4.8 (7 reviews)

29317-E1-XL FAG

dimensions

85 x 150 x 39

Weight

2.693 kg

cage

steel, guided by the rolling elements

country of origin

Germany

Dynamic load rating [N]

420000

limiting speed [rpm]

4850

operating temp.

-30÷200°C

reference speed [rpm]

2260

reinforced execution

yes

static load rating [N]

1110000

T1 - outer ring width [mm]

T3 - inner ring width [mm]

24.5

type

spherical roller thrust bearing

Attributes Substitutes (5)

29317-E1-XL FAG

Spherical roller thrust bearing (operating temp.: -30÷200°C)

manufacturer	FAG
dimensions	85 x 150 x 39
Weight	2.693 kg
T1 - outer ring width [mm]	20
T3 - inner ring width [mm]	24.5
operating temp.	-30÷200°C
type	spherical roller thrust bearing
reinforced execution	yes
Dynamic load rating [N]	420000
static load rating [N]	1110000
cage	steel, guided by the rolling elements
country of origin	Germany
limiting speed [rpm]	4850
reference speed [rpm]	2260
