You are here: Linear motion Linear bearings Linear ball bearings SMT8GUUE NB

SMT8GUUE

Flanged ball bushing

SMT8GUUE NB

dimensions	8 x 15 x 24
Weight	0.034 kg
cage	plastic
country of origin	Japan
D1 - flange diameter [mm]	32
d [mm]	8
D [mm]	15
e - flange thickness [mm]	5
flange	two side cut
f [mm]	5
J [mm]	24
L [mm]	24
material	steel

Plewiska (7)

on stock

Log in to see the price

Attributes Substitutes (1)

SMT8GUUE NB

Flanged ball bushing

Log in to see the price

Attributes

manufacturer	NB
dimensions	8 x 15 x 24
Weight	0.034 kg
d [mm]	8
D [mm]	15
D1 - flange diameter [mm]	32
e - flange thickness [mm]	5
f [mm]	5
flange	two side cut
L [mm]	24
material	steel
type	flanged ball bushing
sealing	double-sided rubber, contact
W [mm]	21
X [mm]	3.5
Y [mm]	6
Z - depth [mm]	3.1
J [mm]	24
cage	plastic
country of origin	Japan
rolling element material	steel

Technical materials

catalog

Product's substitutes

LMHP08UU SAMICK

LMHP08UU SAMICK

Flanged ball bushing

8 x 15 x 24

in stock

Plewiska: 50 pcs

Log in to see prices
