GRLA-1/4-QS-10-RS-D FESTO
Pressure regulator
Feature | Value |
---|---|
Valve function | One-way flow control function |
Pneumatic connection, port 1 | QS-10 |
Pneumatic connection, port 2 | G1/4 |
Adjusting element | Knurled screw |
Mounting type | Threaded with external (male) thread |
Standard nominal flow rate in flow control direction | 480 l/min |
Standard nominal flow rate in non-return direction | 345 ... 500 l/min |
Operating pressure | 0.2 ... 10 bar |
Ambient temperature | -10 ... 60 °C |
Maritime classification | see certificate |
Assembly position | Any |
Operating pressure complete temperature range | 0.2 ... 10 bar |
Standard flow rate in flow control direction 0.6->0 MPa (6->0 bar, 87->0 psi) | 760 l/min |
Standard flow rate in non-return direction at 0.6->0 MPa (6->0 bar, 87->0 psi) | 630 ... 790 l/min |
Operating medium | Compressed air in accordance with ISO8573-1:2010 [7:4:4] |
Note on operating and pilot medium | Lubricated operation possible (subsequently required for further operation) |
Storage temperature | -10 ... 40 °C |
Medium temperature | -10 ... 60 °C |
Nominal tightening torque | 5 Nm |
Product weight | 50 g |
Materials note | Conforms to RoHS |
Material seals | NBR |
Material hollow bolt | Wrought Aluminium alloy Anodised |
Material release ring | POM |
Material knurled head | Wrought Aluminium alloy Anodised |
Material adjusting screw | High alloy steel, non-corrosive |
Material swivel fitting | Zinc die-casting |
manufacturer | FESTO |
dimensions | 12 x 0 x 0 |
Weight | 0.047 kg |
working pressure [bar] | 0,2÷10 |
material | POM |
type | pressure regulator |
country of origin | Germany |
valve function | One-way flow control function |
working medium | Sprężone powietrze wg ISO8573-1:2010 [7:4:4] |
