Name: UKFL209-J7 FAG
Rating: 5 (10 reviews)

UKFL209-J7 FAG

dimensions

40 x 0 x 0

Weight

2.075 kg

A1 [mm]

A [mm]

cage

polyamide

clearence

C4 - greater than C3

Dynamic load rating [N]

34500

d [mm]

J [mm]

148

L2 [mm]

108

L [mm]

188

N [mm]

sealing

double-sided lip seal covered with a steel sheet washers with outer flinger shield with corrosion protection.

Attributes Substitutes (4)

UKFL209-J7 FAG

Cast iron bearing unit with adapter sleeve

Attributes

manufacturer	FAG
dimensions	40 x 0 x 0
Weight	2.075 kg
A [mm]	38
d [mm]	40
L [mm]	188
L2 [mm]	108
clearence	C4 - greater than C3
N [mm]	19
tolerance	hole tolerance in the housing J7, not H7 (tighter fit - standard for FAG)
type	cast iron bearing unit with adapter sleeve
sealing	double-sided lip seal covered with a steel sheet washers with outer flinger shield with corrosion protection.
used with	H2309
A1 [mm]	18
J [mm]	148
Dynamic load rating [N]	34500
static load rating [N]	20400
cage	polyamide
taper	taper 1:12
