You are here: Power transmission Drive belts and pulleys Timing belts and pulleys HDB38-14M40 SIT

38 14M 40 (2517)

38 14M 40 (2517)

38 14M 40 (2517)

38 14M 40 (2517)

38 14M 40 (2517)

38 14M 40 (2517)

Pulley

HDB38-14M40 SIT

TL 38 14M 40 (2517) SIT PBH38-14M40 SIT

dimensions	0 x 166.6 x 54
Weight	5.727 kg
bo - belt width [mm]	40
country of origin	China
execution	5
E [mm]	183
feature	pulley with flanges
feature	taper bushing mounting
feature	no hub
material	carbon steel C45 / 1.0503 / AISI1045
number of teeth	38
profile	14M
R [mm]	169.34

Plewiska (1)

on stock

Log in to see the price

SIT

Attributes Substitutes (1)

HDB38-14M40 SIT

Pulley

Log in to see the price

manufacturer	SIT
dimensions	0 x 166.6 x 54
Weight	5.727 kg
bo - belt width [mm]	40
feature	pulley with flanges
feature	taper bushing mounting
feature	no hub
E [mm]	183
number of teeth	38
material	carbon steel C45 / 1.0503 / AISI1045
S [mm]	166.6
type	pulley
W [mm]	54
used with	Taper Lock 2517
Y [mm]	45
Z - depth [mm]	4.5
execution	5
profile	14M
R [mm]	169.34
U [mm]	130
country of origin	China

Technical materials

Product's substitutes

PHP 38-14M-40TB SKF

PHP 38-14M-40TB SKF

Pulley

0 x 0 x 0

Log in to ask for price and availability
