You are here: Power transmission Drive belts and pulleys Timing belts and pulleys PBD20L075 SIT

20 L 075 (1108)

20 L 075 (1108)

20 L 075 (1108)

20 L 075 (1108)

20 L 075 (1108)

20 L 075 (1108)

Pulley

PBD20L075 SIT

TL 20 L 075 (1108) SIT

dimensions	0 x 59.88 x 25
Weight	0.29 kg
bo - belt width [mm]	075 (3/4"=19,05 mm)
country of origin	China
ds [mm]	0
execution	4
E [mm]	66.5
feature	no hub
feature	pulley with flanges
feature	taper bushing mounting
material	carbon steel C45 / 1.0503 / AISI1045
number of teeth	20
profile	L

Plewiska (10)

on stock

Log in to see the price

SIT

Attributes Substitutes (1)

PBD20L075 SIT

Pulley

Log in to see the price

manufacturer	SIT
dimensions	0 x 59.88 x 25
Weight	0.29 kg
bo - belt width [mm]	075 (3/4"=19,05 mm)
feature	no hub
feature	pulley with flanges
feature	taper bushing mounting
E [mm]	66.5
number of teeth	20
material	carbon steel C45 / 1.0503 / AISI1045
S [mm]	59.88
type	pulley
W [mm]	25
used with	Taper Lock 1108
Y [mm]	22
Z - depth [mm]	3
execution	4
profile	L
ds [mm]	0
R [mm]	60.64
U [mm]	46
country of origin	China
