Name: S6204 E TA P4+ UL GMN
Rating: 4.7 (5 reviews)

S6204 E TA P4+ UL GMN

dimensions

20 x 47 x 14

Weight

0.108 kg

bearing arrangement

for universal matching

cage

textolite, outer ring centred

contact angle [°]

country of origin

Germany

Dw - rolling element diameter [mm]

7.938

Dynamic load rating [N]

16200

limiting/attainable speed, grease [rpm]

32000

limiting/attainable speed, oil [rpm]

43000

precision

better than P4

preload

light preload

product feature

high precision bearing

Attributes Substitutes (10)

S6204 E TA P4+ UL GMN

Single row angular-contact ball bearing, high precision bearing

manufacturer	GMN
dimensions	20 x 47 x 14
Weight	0.108 kg
type	single row angular-contact ball bearing
product feature	high precision bearing
Dynamic load rating [N]	16200
static load rating [N]	9800
contact angle [°]	25
cage	textolite, outer ring centred
preload	light preload
bearing arrangement	for universal matching
precision	better than P4
Dw - rolling element diameter [mm]	7.938
country of origin	Germany
limiting/attainable speed, oil [rpm]	43000
limiting/attainable speed, grease [rpm]	32000
rolling element material	big steel balls
rings material	steel

Technical materials

leaflet

Product's substitutes

7204 ACD/P4ADGA SKF

Single row angular-contact ball bearing, high precision ball bearings set, (two pcs)

20 x 47 x 14

in stock

Plewiska: 2 pair

7204 ACDGA/P4A SKF

Single row angular-contact ball bearing, high precision bearing

20 x 47 x 14

in stock

Plewiska: 8 pcs

7204 ACYU/GL P4 NACHI

Single row angular-contact ball bearing, high precision bearing

20 x 47 x 14

B7204ETSULP4 RHP

Single row angular-contact ball bearing, high precision bearing

20 x 47 x 14

in stock

Olsztyn: 1 pcs

7204HG1UJ74 SNR

Single row angular-contact ball bearing, high precision bearing

20 x 47 x 14

B7204-E-T-P4S-DUL FAG

Single row angular-contact ball bearing, high precision ball bearings set, (two pcs)

20 x 47 x 14

B7204-E-T-P4S-UL FAG

Single row angular-contact ball bearing, high precision bearing

20 x 47 x 14

in stock

Plewiska: 8 pcs

B7204-E-T-P4S-UL CSC

Single row angular-contact ball bearing, high precision bearing

20 x 47 x 14

in stock

Plewiska: 4 pcs

S6204 E TA P4+ DUL GMN

Single row angular-contact ball bearing, high precision ball bearings set, (two pcs)

20 x 47 x 14

in stock

Plewiska: 2 pair

S6204 E TXM P4+ DUL GMN

Single row angular-contact ball bearing, high precision ball bearings set, (two pcs)

20 x 47 x 14
