dimensions | 31.75 x 85 x 36.5 |
Weight | 0.7 kg |
C - outer ring width (insert bearing) [mm] | 22 |
dk [mm] | 32,95 +0,6 / +0,9 |
d [mm] | 31.75 |
D [mm] | 85 |
groove on outer ring | yes |
inner ring width [mm] | 34.9 |
rounded outer ring | yes |
sealing | labyrinths on both sides. For higher temperatures and less friction. |
type | insert ball bearing with square hole |
DNF245/10GY RHP-NSK
Insert ball bearing with square hole
manufacturer | RHP-NSK |
dimensions | 31.75 x 85 x 36.5 |
Weight | 0.7 kg |
inner ring width [mm] | 34.9 |
C - outer ring width (insert bearing) [mm] | 22 |
d [mm] | 31.75 |
D [mm] | 85 |
dk [mm] | 32,95 +0,6 / +0,9 |
groove on outer ring | yes |
type | insert ball bearing with square hole |
sealing | labyrinths on both sides. For higher temperatures and less friction. |
rounded outer ring | yes |
GVK104-209-KTT-B-HLA INA
Insert ball bearing with square holeC - outer ring width (insert bearing) [mm]: 22
