dimensions | 12 x 0 x 0 |
Weight | 0.092 kg |
A - rod end outer diameter [mm] | 34 |
C - outer ring width [mm] | 8 |
country of origin | Germany |
Dynamic load rating [N] | 11400 |
F - height to the axis [mm] | 54 |
friction pair | steel/bronze |
GL - thread length [mm] | 28 |
inner ring width [mm] | 10 |
L - rod head height [mm] | 71 |
static load rating [N] | 24500 |
thread | M12 |
SAL 12 C SKF
Rod end
manufacturer | SKF |
dimensions | 12 x 0 x 0 |
Weight | 0.092 kg |
A - rod end outer diameter [mm] | 34 |
inner ring width [mm] | 10 |
C - outer ring width [mm] | 8 |
F - height to the axis [mm] | 54 |
GL - thread length [mm] | 28 |
thread | M12 |
L - rod head height [mm] | 71 |
friction pair | steel/bronze |
type | rod end |
Dynamic load rating [N] | 11400 |
static load rating [N] | 24500 |
country of origin | Germany |
thread 2 | external thread, left |
