Name: S609 C TA P4+ DUL GMN
Rating: 4.9 (7 reviews)

S609 C TA P4+ DUL GMN

dimensions

9 x 24 x 7

Weight

0.032 kg

bearing arrangement

universal matching pair

cage

textolite, outer ring centred

contact angle [°]

country of origin

Germany

Dw - rolling element diameter [mm]

3.969

Dynamic load rating [N]

3750

limiting/attainable speed, grease [rpm]

77000

limiting/attainable speed, oil [rpm]

100000

precision

better than P4

preload

light preload

product feature

high precision ball bearings set, (two pcs)

Attributes Substitutes (8)

S609 C TA P4+ DUL GMN

Single row angular-contact ball bearing, high precision ball bearings set, (two pcs)

Attributes

manufacturer	GMN
dimensions	9 x 24 x 7
Weight	0.032 kg
type	single row angular-contact ball bearing
product feature	high precision ball bearings set, (two pcs)
Dynamic load rating [N]	3750
static load rating [N]	1720
contact angle [°]	15
cage	textolite, outer ring centred
preload	light preload
bearing arrangement	universal matching pair
precision	better than P4
Dw - rolling element diameter [mm]	3.969
country of origin	Germany
limiting/attainable speed, oil [rpm]	100000
limiting/attainable speed, grease [rpm]	77000
rolling element material	big steel balls
rings material	steel
